Photovoltaic System Testing Laboratory
Photovoltaic Laboratory is the first laboratory from its type to provide tests and assessments on Photovoltaic modules in Jordan. The laboratory is funded by the European Union.
The laboratory’ instruments are:
|
Figure 1: LED SUN SIMULATOR
|
Figure 2: LED SUN SIMULATOR OUTPUT
|
Figure 3: ELECTROLUMINESCENCE TESTER (EL TEST)
|
|
Figure 4: EL TEST OUTPUT
|
Figure 5: SOLAR PV SIMULATOR
|
Figure 6: UTILITY GRID SIMULATOR
|
|
Figure 7: Solar Installation Test Kit
|
Figure 8: Solar Path Finder
|
Figure 9: High Voltage Insulation Kit
|
|
Figure 10: Infrared Camera
|
Figure 11: DC & AC Power Analyzer
|
Figure 12: IV Curve Tracer
|
